    07-36001 Catalog

    07-36001-A Series Remote Condenser

    Remote Mounted Condenser, Single Motor

    Features

    • Available 12 or 24 volt
    • Single 1 speed motor
    • One 10″ steel 4 bladed fan
    • Steel case with grey powder coat finish
    • Does not include an inline receiver drier or binary switch, if desired see the 07-36002-A

    Specifications

    Unit Number BTU’s Cool Air flow Height Width Depth Weight Motor Current draw
    07-36001-12A 33,000 740 CFM 12.15″ 29.5″ 13.63″ 42 LBS 1 – 12v 12.6 amps @ 13.6 vdc
    07-36001-24A “ “ “ “ “ “ 1 – 24v 6.4 amps @ 26.8 vdc
    Your inquiry has been sent!
    Send An Inquiry
    Category: . Tags: , .

    Product Description

    The 36001-A remote powered condenser is the original, classic single motor design.

    Engineered to withstand the punishing environments of today’s heavy equipment, and based on decades of use, the 36001-A Series is a workhorse in the off-road industry. The 10″ metal fan blades and sealed permanent magnet motors are built to last.

    Click here to see the entire family of remote powered condensers
